QUALITY YOU CAN TRUST
The CX300C excavator brings up to 8% more fuel efficiency and increased durability. The excavator has a robust design and CASE top manufacturing quality.
CX300C
Model – ISUZU GH-6HK1X
Type – Water-cooled, 4-cycle diesel, 6-cylinder in-line, High pressure common rail system (electric control), Turbocharger with air-cooled intercooler.
Number of cylinders/displacement – 6 / 7,79 l
Maximum torque ISO 9249 (Net) – 1020 Nm at 1500 min-1
SAE J 1349, ISO 9249 – 202 kW / 270 hp at 2000 min-1
CX300C
Maximum swing speed – 11,0 min-1
Swing torque – 9250 Nm
CX300C
Main pumps – 2 variable displacement axial piston pumps with regulating system
Max oil flow – 2 x 243 liter/min at 1800 min-1
Boom/Arm/Bucket circuit – 34.3 MPa – 37.3 MPa with auto power boost
